1x16 HDMI 2.0 Distribution Amplifier 18Gbps

VLSP-16H20

Data Sheet

User Manual

Product Description

The VLSP-16H20 is an 18Gbps 1x16 HDMI splitter designed to deliver ultra-high-definition signal distribution from a single HDMI source to up to 16 displays simultaneously. Supporting resolutions up to 4K@60Hz 4:4:4, this high-performance unit ensures exceptional video clarity and consistency across all outputs.

With advanced EDID management and full compatibility with the latest HDR format, including HDR, HDR10, HDR10+, HLG, and Dolby Vision, the VLSP-16H20 offers maximum flexibility for modern AV systems. It’s an ideal solution for applications requiring large-scale HDMI distribution, such as multimedia conference rooms, digital classrooms, broadcast environments, and large-screen display installations.

Engineered for reliability and ease of integration, the VLSP-16H20 delivers professional-grade performance in even the most demanding video environments.

Featured Highlights

  • DMI 2.0b, HDCP 2.2 / 1.x and DVI 1.0 compliant

  • Supports 18Gbps video bandwidth

  • Supports video resolution up to 4K2K@50/60Hz 4:4:4

  • Supports digital audio format: DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/Dolby-AC3/DSD

  • Supports HDR, HDR10, HDR10+, HLG and Dolby vision

  • Advanced EDID management

  • Compact design for easy and flexible installation

Specifications

Technical
HDMI Compliance     HDMI 2.0b
HDCP Compliance     HDCP 2.2/1.x
Video Bandwidth     594MHz / 18Gbps
Video Resolution     Up to 4k2k@50/60Hz 4:4:4
Color Depth     8-bit,10-bit,12-bit(1080p@60Hz)

8-bit (4K2K@60Hz YUV4:4:4)

8-bit,10-bit,12-bit (4K2K@60Hz YCbCr 4:2:2/4:2:0)
Color Space     RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2/4:2:0
HDR     Support HDR, HDR10, HDR10+, HLG, Dolby vision
HDMI Audio Formats     PCM2.0/5.1/7.1CH, Dolby 5.1, DTS5.1, Dolby- TrueHD, DTS-HD
ESD Protection     Human body model—±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Connection
Input         1× HDMI Type A (19-pin female)
Output         16× HDMI Type A (19-pin female)
Control         1× SERVICE (Micro USB, Update port)

1x DIAL switch [5-pin]
Mechanical
Housing     Metal Enclosure
Silkscreen Color     Black
Dimensions     300mm (W) × 100mm (D) × 28mm (H)
Weight     900g
Power Supply    Input: AC100 - 240V 50/60Hz,

Output: DC 12V/2.5A

(US/EU standard, CE/FCC/UL certified)
Power Consumption     12W
Operating Temperature     0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature    -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity    20 - 90% RH (No condensation)
