VLHA-H21ERAD

8K HDMI 2.1 eARC audio adapter that de-embeds audio from an HDMI source or a TV's ARC/eARC to HDMI, S/PDIF, and analog outputs
Full HD audio pass-through up to Dolby Atmos and DTS:X, routed to an AV receiver, amplifier, or eARC soundbar (including Sonos Arc/Beam)
48Gbps HDMI 2.1 video pass-through up to 8K@60 4:2:0 and 4K@120 4:4:4, with HDR10+, Dolby Vision, HLG, VRR, and ALLM
CEC control and volume from the TV to the source or sound system, with EDID management and cable equalization

Where to Buy

Product Description

The VLHA-H21ERAD is a 48Gbps eARC Audio Adapter designed for de-embedding audio signals from an HDMI source or TV with ARC/eARC, and outputting HDMI audio, digital S/PDIF audio or analog audio to AV Receiver. It supports data rates up to 48Gbps complying with HDMI 2.1 and HDCP 2.3 requirements. It includes several features for ease of integration, such as EDID management and cable equalization.

It provides an easy solution for HDMI installations to send audio signals to a soundbar, amplifier or any 5.1/2.0CH sound system. CEC control from TV to the source, amplifier or soundbar is also supported.

Key Features

HDCP 2.3 compliant
48Gbps video bandwidth, up to 8K@60Hz 4:2:0 12-bit and 4K@120Hz 4:4:4 12-bit, per HDMI 2.1
VRR, ALLM, QMS, QFT, and SBTM supported
HDR, HDR10, HDR10+, Dolby Vision, and HLG pass-through
LPCM 7.1CH, Dolby TrueHD, Atmos, DTS-HD Master, and DTS:X pass-through
HDMI input source and TV eARC/ARC audio de-embedded to S/PDIF, L/R, and HDMI audio outputs
HDMI input source routed to any eARC/ARC soundbar
Full audio up to Dolby Atmos/DTS:X from an eARC TV to a Sonos Arc/Beam or any eARC soundbar
CEC control from the TV to the source
CEC volume control from the TV to any eARC sound system
Advanced EDID management

Downloads

DATA SHEET (PDF)

USER MANUAL (PDF)

Specifications


     Technical

     HDMI Compliance
     HDMI 2.1

     HDCP Compliance
     HDCP 2.3

     Video Bandwidth
     48Gbps FRL and 18Gbps TMDS

     Video Resolution
     Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

     Color Depth
     8-bit,10-bit,12-bit

     Color Space
     RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0

     HDR
     HDR, HDR10, HDR10+, Dolby Vision, HLG

     Audio Formats
      HDMI input/output:
LPCM, Dolby Digital/Plus/EX, Dolby

True HD, Dolby Atmos, DTS, DSD

 DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X

  eARC AUDIO OUT:

LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DSD

 DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X

  Amp AUDIO OUT:

LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DSD

 DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X

 Audio de-embedding output:

  Optical:  PCM 2.0CH/Dolby/DTS 5.1CH

 L/R:  PCM 2.0CH

     ESD Protection
     IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

     Connection

     Input
     1 × Source IN [HDMI Type A, 19-pin female]

     Output
      1 × TV(eARC) OUT [HDMI Type A, 19-pin female]

1 × Soundbar eARC OUT [HDMI Type A, 19-pin female]

  1 × Amp AUDIO OUT [HDMI Type A, 19-pin female]

1 × OPTICAL [S/PDIF]
1 × L/R [3.5mm Stereo Mini-jack]

     Control
      1 × SERVICE [USB Type C, Update port]

     Mechanical

     Housing
     Metal Enclosure

     Color
     Black

     Dimensions
     145mm [W] × 68mm [D] × 18mm [H]

     Weight
     262g

     Power Supply
     Input: AC 100-240V 50/60Hz, Output: DC 5V/2A

(US/EU standards, CE/FCC/UL certified)

     Power Consumption
     5.2W (Max)

     Operating Temperature
      0°C ~ 40°C / 32°F ~ 104°F

     Storage Temperature
     -20°C ~ 60°C / -4°F ~ 140°F

     Relative Humidity
     20 - 90% RH (No condensation)
